First module and rudimentary mounting box

The first module is a 'sandbox' for testing the placement of components. Here we have a knob with a 0-10 scale (based on the 'Glide Rate' knob on my Moog Voyager). Also modelled are three 1/4" jack sockets and three 5mm red LEDs in holders. The module's plate has holes drilled in the appropriate places for each component and also has two mounting holes for screwing it into the mounting box.
